Name: Thermal Castable Alumina Based Ceramics Sleeves Tubes Lightweight
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: 95% Alumina Ceramics
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	95% Alumina Ceramics	Color:	White
Density:	3.6g/cm³	Modulus Of Elasticity:	340 Gpa
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	thermal Alumina Based Ceramics , Castable Alumina Based Ceramics , lightweight castable alumina ceramic

Product Description

Thermal Castable Alumina Based Ceramics Sleeves Tubes Lightweight

Product Overview

95% Alumina Ceramics Products with customizable color options and 1900HV1/2 Vickers Hardness. These high-performance ceramic components are ideal for industrial, scientific, military, and other demanding applications.

Key Specifications

Attribute	Value
Material	95% Alumina Ceramics
Color	White (Customizable)
Density	3.6g/cm³
Modulus of Elasticity	340 Gpa
OEM/ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Key Features

High hardness and exceptional wear resistance
Customizable color options available
Excellent performance in high temperature environments
Superior chemical stability and insulation properties
Lightweight yet durable construction

Technical Specifications

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10

Product Applications

Alumina ceramics are widely used in industrial, scientific, military, and other fields due to their high hardness, excellent wear resistance, superior chemical stability, outstanding insulation properties, light weight, and exceptional high temperature resistance.

Product Images

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	95% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
