Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity

Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity
Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity
Basic Information
Place of Origin: WUXI JIANGSU CHINA
Brand Name: HENGYUAN
Certification: CE,UL
Model Number: 99% Alumina Ceramics
Minimum Order Quantity: 100
Price: $1-$20
Packaging Details: Carton
Delivery Time: 20 DAYS
Supply Ability: 5000 PCS/WEEK
Get Best Price
Chat Now
Detail Information
Material: 99% Alumina Ceramics Density: 3.85g/cm³
Flexural Strength: 350 Mpa Color: White Or Yellow
OEM，ODM: Acceptable Orgin: WUXI JIANGSU CHINA
MOQ: 100 PCS Package: Carton
Highlight:

Industrial alumina ceramic insulator

,

High Purity alumina ceramic insulator

,

synthetic high alumina ceramic

Product Description

Industrial Alumina Ceramic Insulator Synthetic Raw Materials High Purity
Product Specifications
Attribute Value
Material 99% Alumina Ceramics
Density 3.85g/cm³
Flexural Strength 350 Mpa
Color White or yellow
OEM/ODM Acceptable
Origin Wuxi Jiangsu, China
MOQ 100 PCS
Package Carton
Product Description

HENGYUAN alumina ceramics are manufactured from Al2O3 synthetic raw materials with aluminum concentrations ranging from 95% to 99.7%. These high-performance ceramics are extensively used in advanced applications including building and sanitary ceramics, high-temperature industrial furnaces, and aerospace components, where their exceptional properties provide critical advantages.

Technical Specifications Comparison
Material Unit A95% Alumina Ceramics A97% Alumina Ceramics A99% Alumina Ceramics A99.7% Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric Constant εr 10 10 10 10
