Name: 97% 99.7% Alumina Ceramic Plunger Thermocouple Insulators For Pharmaceutical
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Ceramic Plunger
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	Ceramic Plunger	Color:	White
Difficulty Of Disassembly:	Easy To Disassemble	Accuracy:	High Precision
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100	Package:	Carton
Highlight:	99.7% Alumina Plunger Ceramic , Thermocouple Plunger Ceramic , thermocouple insulators Plunger

Product Description

97% 99.7% Alumina Ceramic Plunger Thermocouple Insulators For Pharmaceutical

Product Specifications

Material	Ceramic Plunger
Color	White
Difficulty Of Disassembly	Easy To Disassemble
Accuracy	High Precision
OEM/ODM	Acceptable
Origin	Wuxi Jiangsu, China
MOQ	100
Package	Carton

Product Description

Versatile A97% A99.7% Alumina Bushing Ceramic Plunger designed specifically for pharmaceutical and chemical applications. This high-precision ceramic component offers superior performance in demanding industrial environments.

Key Features

High-precision ceramic plunger for pharmaceutical applications
Exceptional corrosion resistance against acids, alkalis, and salts
Easy to disassemble design for maintenance and cleaning
Available in 97% and 99.7% alumina compositions
High-temperature stability up to 1650°C
Superior electrical insulation properties

Material Properties Comparison

Property	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric Constant	εr	10	10	10

Product Advantages

Ceramic plunger pumps deliver exceptional physical performance, making them ideal for various industrial environments. These plungers provide excellent corrosion resistance against acids, alkalis, and salts, ensuring stable operation in challenging conditions.
