Electrical Insulation Alumina Based Ceramics Custom Parts Anti Corrosion

Basic Information

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	99% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Supply Ability:	5000 PCS/WEEK

Get Best Price

Chat Now

Detail Information

Material:	99% Alumina Ceramics	Density:	3.85g/cm³
Flexural Strength:	350 Mpa	Shape:	Customizable
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	Electrical Alumina Based Ceramics , Custom Alumina Based Ceramics , anti corrosion alumina custom parts

Product Description

Electrical Insulation Alumina Based Ceramics Custom Parts

High-performance 99% alumina ceramics offering superior electrical insulation, corrosion resistance, and customizable solutions for industrial applications.

Key Specifications

Attribute	Value
Material	99% Alumina Ceramics
Density	3.85g/cm³
Flexural Strength	350 Mpa
Shape	Customizable
OEM/ODM	Acceptable
Origin	Wuxi Jiangsu, China
MOQ	100 PCS
Package	Carton

Product Advantages

Excellent electrical insulation properties
High mechanical strength (350 Mpa flexural strength)
Outstanding thermal conductivity and shock resistance
Exceptional resistance to high temperatures, corrosion, and wear
Maintains quality under chemical shock and thermal cycling
Customizable shapes and sizes for specific applications

Material Properties Comparison

Property	Unit	A95% Alumina	A97% Alumina	A99% Alumina	A99.7% Alumina
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Conductivity	W/Mk	23	24	27	27
Maximum Use Temperature	℃	1600	1600	1650	1650
