Name: Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: 95% Alumina Ceramics
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	95% Alumina Ceramics	Color:	White
Density:	3.6g/cm³	Working Temperature:	1600℃
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	Machined Alumina Based Ceramics , Precision Alumina Based Ceramics , Machined nonporous alumina ceramic tubes

Product Description

Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering

Product Attributes

Attribute	Value
Material	95% Alumina Ceramics
Color	White
Density	3.6g/cm³
Working Temperature	1600℃
OEM，ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Product Description

95% Alumina Ceramics High Insulation And Heat Resistance 1600℃ For Precision Engineering

Alumina ceramic parts are widely used in electrical appliances, petrochemical, machinery, textiles, automobiles and other industries. Alumina ceramics are currently divided into two types: high purity type and ordinary type. When the content of alumina ceramics is below 99%, it appears pure white. When the content reaches 99% and above, the color of the ceramic is typically light yellow.

Technical Properties Comparison

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10

Product Images

95% Alumina Ceramic component

Close-up of ceramic surface

Industrial application

High temperature resistant components

Ceramic ring with high insulation

Precision components

Smooth surface finish

Various sizes available

Precise dimensions

Electrical insulation parts

1600℃ resistance

Consistent quality

Mechanical system components

High density parts

Customizable components

Quality control inspection

Heat resistant ceramic ring

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	95% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
