Name: Recrystallized Alumina Based Ceramics For Bulletproof Armor Abrasion Resistance
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: 95% Alumina Ceramics
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	95% Alumina Ceramics	Color:	White
Heat Resistance Level:	High Heat Resistance	Shape:	Customizable
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	Recrystallized Alumina Based Ceramics , armor Alumina Based Ceramics , armor recrystallized alumina

Product Description

Recrystallized Alumina Based Ceramics For Bulletproof Armor & Abrasion Resistance

Key Specifications

Attribute	Value
Material	95% Alumina Ceramics
Color	White
Heat resistance level	High heat resistance
Shape	Customizable
OEM/ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Our premium 95% alumina ceramics are engineered for optimal performance in harsh mechanical and electrical environments. These high-performance ceramics offer exceptional durability and protection, making them ideal for demanding industrial applications.

Material Properties

Alumina ceramics exhibit outstanding mechanical and thermal properties that make them indispensable for critical applications including bulletproof armor systems. Their exceptional hardness and toughness provide reliable protection against ballistic threats in body armor plates and vehicle armor applications.

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10

Product Gallery

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	95% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
