340 Gpa Insulating 95% Alumina Ceramics Materials 3.6 g/cm³ Various Components Customized

Basic Information

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	95% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK

Get Best Price

Chat Now

Detail Information

Material:	95% Alumina Ceramics	Color:	White
Density:	3.6 G/cm³	Maximum Use Temperature:	1600 ℃
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	alumina ceramic density 3.6 g/cm³ , 340 Gpa 95 alumina ceramic , high purity alumina 3.6 g/cm³

Product Description

340 GPa Insulating 95% Alumina Ceramics

Product Specifications

Attribute	Value
Material	95% Alumina Ceramics
Color	White
Density	3.6 g/cm³
Maximum Use Temperature	1600 ℃
OEM/ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Product Description

Alumina ceramic (Al2O3) is an industrial ceramic material known for its high hardness, exceptional wear resistance, and requires diamond grinding for shaping. Due to its outstanding performance characteristics, alumina ceramic is widely used across various industrial applications.

Key Features

Customizable shapes to meet specific requirements
Standard white color
High thermal conductivity for efficient heat transfer
Excellent corrosion resistance for harsh environments

Technical Properties

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric Constant	εr	10	10	10	10
