340 Gpa 95% Alumina Ceramics 3.6g/cm³ Insulator High Heat Resistant Al2O3 Custom Parts

Basic Information

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	95% Alumina Ceramics

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK

Get Best Price

Chat Now

Detail Information

Material:	95% Alumina Ceramics	Color:	White
Weibull Modulus:	10M	Modulus Of Elasticity:	340 Gpa
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton
Highlight:	340 gpa 95% alumina ceramics , 340 gpa 95 alumina ceramics , white 95 alumina ceramics

Product Description

340 Gpa 95% Alumina Ceramics 3.6g/cm³ Insulator High Heat Resistant Al2O3 Custom Parts

Product Specifications

Material	95% Alumina Ceramics
Color	White
Weibull Modulus	10M
Modulus of Elasticity	340 Gpa
OEM/ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Product Description

Alumina Ceramic is widely used in various industries due to its excellent electrical insulation properties, high corrosion resistance, and exceptional wear resistance. With a maximum working temperature of 1600°C and outstanding thermal conductivity, it performs reliably in demanding industrial applications.

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10
