Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace

Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace
Basic Information
Place of Origin: WUXI JIANGSU CHINA
Brand Name: HENGYUAN
Certification: CE,UL
Model Number: Alumina Ceramic Crucible
Minimum Order Quantity: 100
Price: $1-$20
Packaging Details: Carton
Delivery Time: 20 DAYS
Payment Terms: L/C, T/T
Supply Ability: 5000 PCS/WEEK
Get Best Price
Chat Now
Detail Information
Material: Alumina Ceramic Crucible Color: Yellow Or White
Shape: Customization Usage: Industry Usage
OEM，ODM: Acceptable Orgin: WUXI JIANGSU CHINA
MOQ: 100 PCS Package: Carton
Highlight:

Cylindrical engineered ceramics crucibles

,

Kiln engineered ceramics crucibles

,

Corundum alumina cylindrical crucible

Product Description

Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace
Product Overview
Our alumina ceramic crucibles are essential kiln tools designed to protect ceramic bodies and glazes during high-temperature firing processes. Made from premium refractory clay materials, these crucibles serve as protective containers that shield ceramics from harmful gases and contaminants during firing.
Key Attributes
Attribute Value
Material Alumina Ceramic Crucible
Color Yellow or White
Shape Customizable
Usage Industrial Applications
OEM/ODM Available
Origin Wuxi Jiangsu, China
MOQ 100 PCS
Package Carton
Technical Specifications
Material Unit A95% Alumina Ceramics A97% Alumina Ceramics A99% Alumina Ceramics A99.7% Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric Constant εr 10 10 10 10
Product Gallery
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 0
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 1
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 2
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 3
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 4
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 5
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 6
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 7
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 8
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 9
Cylindrical Corundum Alumina Engineered Ceramics Crucibles For High Temperature Kiln Furnace 10
