Name: Industrial Alumina Ceramic Tube Pipe Heat Resistant Composite Pipeline
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Ceramic Tube
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	Ceramic Tube	Color:	Yellow Or White
Temperature Capability:	High Heat Resistant	Dielectric Constant:	10εr
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100	Package:	Carton
Highlight:	industrial Alumina Ceramic Tube , Heat Resistant Alumina Ceramic Tube , Heat Resistant alumina ceramic pipe

Product Description

Industrial Alumina Ceramic Tube Pipe Heat Resistant Composite Pipeline

Key Features

High temperature resistance for demanding industrial applications
Available in yellow or white ceramic material
Excellent dielectric properties (10εr)
Custom OEM/ODM solutions available
Superior wear resistance for extended service life

Product Specifications

Attribute	Value
Material	Ceramic Tube
Color	Yellow Or White
Temperature Capability	High Heat Resistant
Dielectric constant	10εr
OEM, ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100
Package	Carton

Material Properties

Material	Unit	A95%	A97%	A99%	A99.7%
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10

Our innovative wear-resistant alumina ceramic tube and pipeline composite assembly technology has significantly expanded industrial applications. In demanding sectors like mining, metallurgy, and chemical engineering, conveying systems must withstand extreme environmental conditions including high temperatures, high pressure, and strong corrosion. While traditional single-material pipelines struggle with these requirements, our wear-resistant alumina ceramic pipes can be effectively combined with other materials to create superior composite pipeline systems.

Product Gallery

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	Ceramic Tube

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
