Name: 95% Alumina Ceramic Tube Insulator Thermal Shock Resistant Customised
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Ceramic Tube
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	Ceramic Tube	Color:	Yellow Or White
Temperature Capability:	High Heat Resistant	Dielectric Constant:	10εr
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100	Package:	Carton
Highlight:	95% Alumina Ceramic Tube , Thermal Alumina Ceramic Tube , customised ceramic insulator tube

Product Description

95% Alumina Ceramic Tube Insulator - Thermal Shock Resistant Customized Solution

Key Features

Superior thermal shock resistance with △T℃ of 250
High temperature capability up to 1600℃
Excellent dielectric properties (10εr constant)
Outstanding wear and corrosion resistance
Available in yellow or white color options
Custom OEM/ODM solutions available

Technical Specifications

Attribute	Value
Material	Ceramic Tube
Color	Yellow or White
Temperature Capability	High Heat Resistant
Dielectric Constant	10εr
Customization	OEM/ODM Acceptable
Origin	Wuxi Jiangsu, China
MOQ	100 units
Package	Carton

Material Properties

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric Constant	εr	10	10	10	10

Product Description

Our alumina ceramic tubes are engineered for industrial applications requiring exceptional thermal stability and mechanical durability. These components outperform traditional metal pipes in harsh environments, offering superior resistance to wear, corrosion, and extreme temperatures.

With a low thermal expansion coefficient (5.0-8.3 x 10-6K-1) and high thermal shock resistance (△T℃ 250), these ceramic tubes maintain dimensional stability under rapid temperature changes, making them ideal for demanding thermal applications.

Product Gallery

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	Ceramic Tube

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
