Name: High Density Mullite Alumina Ceramic Tube Corrosion Resistance Custom
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Ceramic Tube
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	Ceramic Tube	Color:	Yellow Or White
Temperature Capability:	High Heat Resistant	Dielectric Constant:	10εr
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100	Package:	Carton
Highlight:	Mullite Alumina Ceramic Tube , Corrosion Resistance Alumina Ceramic Tube , Corrosion Resistance mullite ceramic tubes

Product Description

High Density Mullite Alumina Ceramic Tube - Corrosion Resistant Custom Solutions

Product Overview

Industrial-grade alumina ceramic tubes designed for high-temperature wear resistance in demanding industrial applications. These advanced ceramic components serve as superior transportation protective materials in mining, metallurgy, and chemical engineering environments. Manufactured using isostatic pressing technology with precise process control, they deliver exceptional density, wear resistance, and corrosion resistance - significantly improving production efficiency while reducing maintenance costs.

Key Attributes

Attribute	Specification
Material	Ceramic Tube
Color	Yellow or White
Temperature Capability	High Heat Resistant
Dielectric Constant	10εr
Customization	OEM/ODM Acceptable
Origin	Wuxi Jiangsu, China
Minimum Order Quantity	100 units
Packaging	Carton

Technical Specifications

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric Constant	εr	10	10	10	10

Product Gallery

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	Ceramic Tube

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
