Name: Anti Wear Technical Alumina Ceramic Components 75dB For Crusher
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Alumina Ceramic Crusher Parts
Price: 10.00 USD
Availability: InStock

Detail Information

Material:	Alumina Ceramic Crusher Parts	Color:	Yellow Or White
Maximum Use Temperature:	1600-1650℃	Wear Resistance:	High Wear Resistance
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100	Package:	Carton
Highlight:	anti wear Alumina Ceramic Components , 75dB Alumina Ceramic Components , 75dB technical ceramic components

Product Description

Anti Wear Technical Alumina Ceramic Components 75dB For Crusher

Product Overview

High wear resistance alumina ceramic crusher parts designed for industrial crushing applications. These components offer superior durability and performance in demanding environments.

Key Features

Working noise below 75 decibels (dB) with minimal dust pollution
Ideal for crushing medium hard and extra hard materials
Produces cubic-shaped output with high packing density
Minimal iron contamination during operation
Self-lining impeller design with low wear and easy maintenance

Product Specifications

Material	Alumina Ceramic Crusher Parts
Color	Yellow or White
Maximum Use Temperature	1600-1650℃
Wear Resistance	High Wear Resistance
OEM/ODM	Acceptable
Origin	Wuxi Jiangsu, China
MOQ	100
Package	Carton

Technical Specifications

Material	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardness	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric Constant	εr	10	10	10	10

Product Images

High wear resistance components

Yellow ceramic components

White ceramic parts

Close-up of industrial parts

Durable crushing components

Heat resistant ceramic ring

Precision crusher parts

Industrial-grade components

Heavy-duty crushing parts

High performance ceramic ring

Tag:

Place of Origin:	WUXI JIANGSU CHINA
Brand Name:	HENGYUAN
Certification:	CE,UL
Model Number:	Alumina Ceramic Crusher Parts

Minimum Order Quantity:	100
Price:	$1-$20
Packaging Details:	Carton
Delivery Time:	20 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	5000 PCS/WEEK
